Alpha Xenon Light Source  300w

Alpha Xenon Light Source 300w

Product Details:

X

Product Description

DESCRIPTION:-

The Alpha Xenon 300w is high pressure lamp which provides exceptional illumination of  the endoscopic field of  operation at the output of the fiber optics  the regained light energy is about 1500 lumens i.e. (tour times the energy of halogen 250 w Bulb) Intensity can be adjusted electronically from 0% to 100%. Life span of bulb is 500 hrs also available timer.

TECHNICAL SPECIFICATIONS

Lamps

Xenon 300w Double Ended

Life span of Lamp

500 Hrs

Light Guide Connection

Storz Type

Aperture

Electronic Control

Colour Temperature

6000° K

Operation Temperature

+ 10° C to 40° C

Operation Humidity

10% to 90%

Dimension (W x H x D)mm

305x137x315

Weight

8 KG

Voltage for Unit

270 VAC

Frequency

50 HZ

Power Consumption

470W Maximum

Main Fuses

5 A



CLASIFICATION

Safety Class

1

Type

BF

Manufactured and  Tested Acc to

IEC 601-1-1 & IEC 601-1-2

Classification of Directive 93/42  EEC

I



SCOPE OF SUPPLY

Alpha Xenon Light Source 300w Consist of

Light Source Unit

XEN-300

1

Mains Cord

MC-03

1

Xenon Lamp 300w

XL-300

1

Fuse

5A

2

User Manual

UM-XEN-300

1



SCOPE OF SUPPLY

Alpha Xenon Light Source 180w Consist of

Light Source Unit

XEN-180

1

Mains Cord

MC-03

1

Xenon Lamp 180w

XL-180

1

Fuse

5A

2

User Manual

UM-XEN-180

1
